TAT Liquid Stamp HD

Marking stamp for identification, featuring a soft rubber surface that allows for marking on uneven and curved surfaces.

Line-up

Self-inking stamp capable of continuously marking on a wide range of materials, including metal, plastic and rubber. It is capable of clear markings on dark coloured materials and uneven surfaces, and can be used instead of a paint marker as an identification stamp.

  • TAT Liquid Stamp HD

Self-inking stamp capable of continuously marking on a wide range of materials, including metal, plastic and rubber. It is capable of clear markings on dark coloured materials and uneven surfaces, and can be used instead of a paint marker as an identification stamp.

Item name
TAT Liquid Stamp HD
Item code
TBS-LSHDA
  • REFILLABLE

    Refill ink is available

  • WORLDWIDE LANGUAGE LOCAL LANGUAGE IS AVAILABLE

  • ONLY INK CONFORMS TO RoHS

  • TAT Liquid Stamp HD

    Watch 0:34–1:04 to check how to refill ink.

Impression examples

  • Contact us to request a custom impression. Not suited for text.

Features

Marking stamp for identification with soft impression die.

Liquid Stamp HD is a self-inking stamp capable of continuously marking on a wide range of materials, including metal, plastic and rubber.
It is capable of clear markings on dark coloured materials and uneven surfaces, and can be used instead of a paint marker as an identification stamp.
Simple operation, Liquid Stamp HD increases productivity.

Reliable quality even when used continuously

The liquid type mechanism transfers just the right amount of ink to the impression die each time, so that impressions do not become fuzzy even when used continuously.
A single ink tank allows for approximately 1,600 continuous markings.
The airtight structure helps prevent the stamp from drying out when not in use, and helps prevent impression from becoming blurry even during extensive use.

Capable of marking uneven surfaces

The impression die is soft, allowing for clear markings even on uneven surfaces of around 1 mm in depth.
It uses special ink, allowing for clear markings even on dark colours including black, and can be used to stamp a wide range of materials including metal, plastic, rubber, glass, wood and leather.

Uses highly safe ink

The stamp uses ink compliant with Export Trade Control Order regulations, the Ozone Layer Protection Act, RoHS directives and ELV regulations for safe to use.

Compatible TAT inks

  • No ink is provided with the product
  • Use the special refill ink for Liquid Stamp HD
TypeItem codeInk colour
Quick dry STO-1/LSA-Y YELLOW
STO-1/LSA-R RED
STO-1/LSA-W WHITE
STO-1/LSA-B BLUE
STO-1/LSA-G GREEN
STO-1/LSA-P PINK
STO-1/LSA-OR ORANGE
STO-1/LSA-V PURPLE
STO-1/LSA-LB LIGHT BLUE
STO-1/LSA-YG YELLOW GREEN
STO-1/LSA-BR BROWN
STO-1/LSA-GR GREY
STO-1/LSA-K BLACK
  • Contents: 55ml
  • Performance may vary depending on the surface conditions of the object to be stamped and usage conditions.
  • White ink is not suitable for highly absorbent paper and cloth.
  • When white ink is used, stamping is required every day, even when it is not necessary, to avoid clogging of the impression surface.
  • Please store the Liquid Stamp in an aluminium bag to prevent drying of the ink.

Specifications

Product size W25.7 x D26.5 x H96.1㎜ (When stamping)
W25.7 x D26.5 x H118.3㎜ (When not in use)
Impression size Φ10.5mm
Weight approx. 26g
Ink tank volume 4ml
Number of continuous stamps approx. 1,600 times*
Drying time approx. 4-5 minutes*
  • Reference for the Number of Impressions…
    Ink Volume: 4 ml
    Stamping Surface: PET film
    Test Environment: temperature 20°C, and Humidity 65%
    Stamping Orientation: Vertical downward stamping
  • Reference for Drying Time…
    Stamping Surface: Rubber sheet
    Test Environment: temperature 20°C,and Humidity 65%
  • Specifications are subject to change without notice.
